Sai ovislink platinum 20k on line 3 - 3 20kva torre trifasico
- €4.455,00
€0,00- €4.455,00
- Unit price
- per
Main input input voltage 380v - 400v - 415v(line to line) - 50 - 60hz input connectión 3ph+n+pe power factor >0.99 input voltage window +25%~ - 20% - full load...
Please hurry! Only 1 left in stock
Hurry up! Sale ends in:
151Days
8Hours
23Minutes
0Seconds
10 customers are viewing this product
Free Shipping
Free standard shipping on orders over $99
Estimated to be delivered on 12/01/2023 - 15/10/2023.
Free Returns
Learn More.
Covid-19 Shipping Delay Notice
Sai ovislink platinum 20k on line 3 - 3 20kva torre trifasico
Main input
input voltage 380v - 400v - 415v(line to line) - 50 - 60hz
input connectión 3ph+n+pe
power factor >0.99
input voltage window +25%~ - 20% - full load
- 20%~ - 40% - power derating between 100% to 70%
frequency window 40 - 70hz
bypass input
bypass voltage 380v - 400v - 415v
bypass voltage window +15% - - 20% - full load
frequency window ±5hz
battery
battery voltage ±240vdc
charger power 20%*power
charger voltage precisión 1%
output
voltage precisión ±0.5% (balance load) -1% (unbalance load)
output voltage transient 5%(0~100% load step)
voltage thd(total harmonic distortión) thd<1%(linear load) -thd<5%(nonlinear
load)
power factor 0.8
frequency tracking range 50 - 60hz±3hz - adjustable
frequency precisión (free running) ±0.02%
phase tolerance 120°±0.5° (balance and unalance load)
voltage unbalance degree (100% unbalance load) ±1%
frequency tracking speed 0.5hz - s to 5hz - s - adjustable
crest factor 3:1
overload capabiltiy 102% long time operatión
110% - transfer to bypass after 1hour
125% - transfer to bypass after 10 minutes
150% - transfer to bypass after 1 minute
>150% - transfer to bypass after 200ms
bypass overload capability 125% - long time operatión
125%< load <130% - last for more than 1 hour
130%
>1000% - last for more than 100ms
system
system efficiency normal mode: 95%
eco mode: 99%
battery mode efficiency 95%
battery configuratión 12v - 40pcs (36~44pcs acceptable)
display lcd+led - keyboard
emi iec62040 - 2
ems iec61000 - 4 - 2(esd)
iec61000 - 4 - 3(rs)
iec61000 - 4 - 4 (eft)
iec61000 - 4 - 5 (surge)
insulatión resistance >2m (500vdc)
dielectric strengh (input -output to pe)2820vdc - leakage current lower than 3.5ma -
no flashover in 1 minute
surge protectión comply with iec60664 - 1 class iv - endure surge of 1.2 - 50us +
8 - 20us higher than 6kv - 3ka
ip class ip20
interface (communicatión ports ) rs232 -rs485 -dry contacts -snmp
card -epo -generator interface
installatión - connectión top or bottom cable connectión
operatión temperature 0 - 40
relative humidity 0 - 90% (non - comdensing)
noise(db) <55db
